Max. running speed (km/h) | 82 | |
Drive System | 8×4 | |
Capacity (Load) | 20-30T | |
Dimensions (L*W*H)(mm) |
Overall | 9735×2490×3790 |
Dump body | 7600×2300×1700 | |
Thickness (mm) | Bottom 8, side 6 | |
Hydraulic lifting system | Ф200 Before the lifting Ф200 | |
Approach / departure angle (°) | 28 / 20 | |
Kerb weight (kg) | 15500 | |
Total mass (kg) | 31000 | |
Wheel base (mm) | 1800+3775+1400 | |
Engine | WEICHAI WP10.380E201 Euro Ⅱ | |
Horsepower | 420 hp | |
Gearbox | FAST 10JSD180 | |
Clutch | Ф 430 Diaphragm type Ф 430 | |
Steering | ZF technology | |
Cab | F3000 mid-lengthened Cabin with single-sleeper F3000 |
|
Axle | Front axle | 9.5T MAN |
Rear axle | 16Ton MAN axle, final ratio 5.262 |
|
Tyre (radial tyre) | 12.00R20 | |
Oil tank | 300L(Metal) |
