| Truck Model | 8X4 | |
| Truck Brand | SINOTRUCK –HOWO | |
| Dimension(Lx W xH)（unloaded）（mm） | 9630X2550X3450 mm | |
| Cargo body size (L*W*H) | 5400 x 2300 x 1500 mm | |
| Cargo body thickness(mm) | bottom:8mm, side:6mm | |
| Lift type of Carriage | Central lifting | |
| Approaching angle/Departure angle（°） | 17/21 | |
| Overhang(front/rear) (mm) | 1500/1870 | |
| Wheel base (mm) | 3625+1350 | |
| Max speed（km/h） | 75 | |
| Curb weight（kg） | 15500 | |
| Loading Weight（kg） | 15370 | |
| Fuel tanker capacity(L) | 300L with locking fuel cap | |
| Clutch | Single-plate dry clutch Φ430mm | |
| Engine Model (Steyr technology, made in China) |
Model | WD615.47，4- stroke direct injection diesel engine, 6 cylinders in line with water cooling , turbo-charging and inter-cooling |
| Horse Power | 460HP, 9.726L | |
| Emission | EURO III | |
| Fuel Type | Diesel | |
| Transmission | Model | HW19710,10 forwards and 2 reverse |
| Brake system | Service brake | Dual circuit compressed air brake |
| Parking brake | spring energy, compressed air operating on rear wheels | |
| Auxiliary brake | Engine exhaust brake | |
| Steering system | Model | hydraulic steering with power assistance Ratio：22.2-26.2 |
| Front axle | HF9 Loading capacity:9000KG |
|
| Rear axle | HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels Loading capacity: 16000kg |
|
| Color | Optional | |
| Tire | 12.00R20 18PR | |
| Cab | HOWO76 cab | |
