Model: |
DFS3060GL6 |
Engine |
|
Model |
B140 33 (Cummins) |
Type |
Diesel, Direct Injection,Turbo charged with Intercooler |
Max. Engine Output (HP or KW/rpm) |
103 KW(140HP) |
Max. Tourque (N.m/rpm): |
502 Nm @ 1400-1600 rpm |
Cylinder Displacement L/cc |
3900 ml |
Emission: |
Euro 3 |
Gear Box |
MT / Forward 5 & Reverse 1 |
Model |
DF5S650 |
Suspension |
Strengthen spring |
Type |
Spring Leaf Tablet: 9/11+8 |
Brakes |
Front&Rear drum,dual-circult service brakding system |
Clutch |
|
Type: |
Single,dry,diaphragm spring clutch⊙350 |
Overall Dimensions (LxWxH) mm: |
6900×2490×2800 |
Wheel Track (front/rear) mm: |
1845 / 1730 |
Overhang (Front/Rear) mm: |
1180 / 1920 |
Driving Type: |
4×2 |
Wheel Base (mm): |
3800 |
Min ground clearence (mm): |
286 |
Vehicle Weight |
|
Curb weight (kg): |
4600 |
Pay Load Capacity (kg): |
10000 |
Gross vehicle weight (kg): |
14600 |
Tipper Body |
|
Volume |
4500×2300×800 8.28 CUM |
Tipping Angle |
45~56° |
Cabin: |
1+2 seats / 2 doors + 1 bed, with Air conditioner |
Steering |
|
Type: |
Power steering |
Wheels & Tyres |
|
Front: |
Tire Number: 2, Tire Size: 8.25R20 |
Rear: |
Tire Number: 4, Tire Size: 8.25R20 |
Performance |
|
Max speed (km/h): |
85 |
