| Basic information | |||
| Announcement type: | ZZ3317V326GF1 | Driving form: | 8X4 |
| Wheelbase: | 1950+3225+1350mm | Engine: | Weichai WP12.430E62 |
| Transmission: | 12-speed transmission | Body length: | 9.93 m |
| Body width: | 2.55m | Body height: | 3.55m |
| Front wheel base: | 2022/2022mm | Rear wheel base: | 1860/1860mm |
| Vehicle weight: | 15.5 tons | Rated load: | 15.37 tons |
| Total mass: | 31 tons | Tonnage class: | Heavy truck |
| Approach Angle: | 17 degrees | Departure Angle: | 21 degrees |
| Engine parameter | |||
| Engine type: | Weichai WP12.430E62 | Engine brand: | Weichai |
| Number of cylinders: | 6 | Type of fuel: | Diesel oil |
| Displacement: | 11.6 L | Emission standard: | Six kingdoms |
| Maximum horsepower: | 430hp | Maximum output power: | 316kW |
| Maximum torque: | 2100 n. m | Maximum torque speed: | 1000-1400rpm |
| Rated speed: | 1900rpm | Engine form: | CR+DOC+DPF+Hi_SCR |
| Container parameter | |||
| Length of container: | 6.8 m | Width of container: | 2.35m |
| Container height: | 1.5m | Container form: | Self-discharging type |
| Transmission parameter | |||
| Transmission model: | 12-speed transmission | Forward gear: | 12th gear |
| Number of reversals: | 2 | ||
| Chassis parameter | |||
| Allowable load of front axle: | 6500/7000kg | Rear axle allowable load: | 17500(biaxial group)kg |
| Number of spring pieces: | 2007/7/10 | ||
| tyre | |||
| Tire specifications: | 12.00 R20 | Number of tires: | 12 |
