| Vehicle brand | AUMARK C 4W | |
| Vehicle model | BJ1041V8JD3-RF | |
| Cabin | A1800 Single row seat，tiltable | |
Whole vehicle main dimensions |
Overall dimensions (LxWxH) mm | 4850×1830×2170(Chassis） |
| Inner dimensions of the cargo body (LxWxH) mm | 3340×1810×360 | |
| Wheel base (mm) | 2600 | |
| Min. ground clearance (mm) | 180 | |
| Driving type | 4×2 | |
| Wheel track (front/rear) (mm) | 1510/1485 | |
Weight data |
Curb weight (kg) | chassis：1900 |
| Rated payload （kg） | 2010 | |
| Persons in cab (persons) | 2 | |
| Gross vehicle weight（kg） | 4300 | |
Whole vehicle main performance |
Max. speed（km/h） | 110 |
| Max. slope of climb（%） | 42 | |
| Fuel consumption（L/100km） | 11.2 | |
| Min. turning diameter（m） | 11.4 | |
Engine |
Model | Cummins ISF2.8s3129T(EuroⅢ) |
| Type | high pressure common rail,Four-cylinder、In-line、Four-stroke、Water-cooling、turbocharging middle cooling | |
| Displacement（L） | 2776 | |
| Rated power（kw/rpm） | 96(130PS)/3200 | |
| Max torque （N.m/rpm） | 310/(1600-2700) | |
Gearbox |
Model | ZF5S400 |
| Speed ratio | i1=5.015，i2=2.543，i3=1.536，i4=1.000，i5=0.789，iR=4.481 | |
| Clutch | Type | φ308*φ190 Diaphragm spring clutch |
| Rear axle | Type/Main reducer ratio | Whole banjo type，ratio ：5.125 |
Suspension |
Front suspension/Leaf spring number | leaf spring, non-independent suspension：3 |
| Rear suspension/Leaf spring number | leaf spring, non-independent suspension：6 | |
| Steering gear | Type | Mechanical circular ball type with power steering |
Brake system |
Service brake and boosting Type | hydraulic,front disk brake ,rear drum brake ,ABS |
| Parking brake | Central drum brake | |
| Auxiliary brake | Exhaust brake | |
| Wheels and tyre size | 7.00R16/4+1 | |
Electric device |
Rated voltage | 12V |
| Battery | 120AH | |
| Fuel tank (L) | 80 | |
| Basic equipment |
