Engine | MT13.43-50 Made By SINOTRUK |
Truck Type | 6x4 |
Cab | HW76 one berth, safety belt for drive and co-drive, two seats, air-condition |
Transmission | HW19710, 10 forward and 2 reverse torque:1900N.M |
Front axle | HF9 axle Steering axle |
Driving axle | HC16*2, ratio 5.73 |
Fuel tanker volume | 8*260L |
Wheel base | 3800+1325mm |
Steering | ZF8118 with hydraulic assistence Power from GERMAN |
Tires | 12.00R22.5 ,10+1 pcs one spare tire |
Brake system | Air brake with WABCO value. |
Cargo body size(mm) | 5600*2300*1500,19.32M3 |
Overall dimension(mm) | 8550*2500*3450 |
Thickness | bottom 8, side 6 mm ,normal Shape cargo box. |
Lifting system | Front lifting by hydraulic pump system |
Bumpers | rear and front bumpers in steel material |
Color | According to customer requirements |
