Bucket width (mm) | 2470 |
Bucket capacity (m3) | 0.45 |
Boom length (mm) | 4300 |
Stick length (mm) | 2500 |
Rotation speed (rpm) 10) | 6 |
Walking speed (km/h) | 2.6-4.9 |
Rated power (kw/rpm) | 55.4 |
Displacement (L) | 3.33 |
Bore x stroke (mm) | 94*120 |
The maximum flow rate of the main pump (l/min) | 233 |
Fuel tank (L) | 145 |
Hydraulic oil tank (L) | 53 |
Hydraulic system (L) | 140 |
Engine oil replacement volume (L) | 11.2 |
Coolant (L) | 10 |
Total transport length (mm) | 6579 |
Total transport width (mm) | 2470 |
Total transport height (mm) | 2893 |
Track shoe width (mm) | 450 |
Total track width (mm) | 2470 |
