| Item | Unit | XM200K | |
| Maximum milling width | mm | 2000 | |
| Maximum milling depth | mm | 320 | |
| Milling wheel | Tool spacing | mm | 15/18 |
| Number of tools | 168/146 | ||
| Milling wheel diameter (with tool) | mm | 980 | |
| Milling wheel maximum inclination | ° | 5 | |
| Diesel engines | Cooling method | Water cooling | |
| Model | QSX15 | ||
| Number of cylinders | 6 | ||
| Rated power | kw | 447 | |
| Engine speed | rpm | 2100 | |
| Fuel consumption: full load | l/h | 120 | |
| Speed/grade ability | Working speed | m/min | 0-84 |
| Walking speed | km/h | 0-5 | |
| Theoretical Gradeability (Working Blocks) | % | 80 | |
| Ground clearance | 320 | ||
| Weight / load | Shipping weight | kg | 30000 |
| Working weight | kg | 34000 | |
| Track device | Front track | mm | 1720×300×620 |
| Rear crawler | mm | 1720×300×620 | |
| Box volume | Fuel tank | L | 1400 |
| Hydraulic tank | L | 300 | |
| Water tank | L | 3400 | |
| Electrical system | V | 24 | |
| Conveyor belt device | Aggregate conveyor belt width | mm | 800 |
| Discharging conveyor width | mm | 800 | |
| Conveyor belt conveying capacity | ≤m3/h | 330 | |
| Shipping dimensions | Machinery (length×width×height) | mm | 7650×2580×3000 |
| Belt conveyor (len
