Cat Cold Planers Road Asphalt Cold Milling Machine

Description

Cat Cold Planers are superior road surface finishing equipment designed for efficient, precise road improvement tasks. These cold milling machines provide critical support for building and road construction with their exceptional performance, reliability and flexibility. Cat Cold Planers are equipped with a high-speed rotating milling head that can quickly peel off the road surface to ensure that the smoothness of the road surface meets the design requirements.

Parameter

Specifications

Milling Width	2235 mm
Maximum Milling Depth	330 mm
Rotor Speeds	100 / 109 / 118 rpm
Number of Bits	193

POWER TRAIN

Rated Power	601 kW
Engine	Cat C18 twin-turbo
Maximum Travel Speed	5.9 km/h
Maximum Milling Speed	100 m/min

WEIGHTS

Operating Weight	36700 kg
Transport Weight	32800 kg

DIMENSIONS

Operating Length - Conveyor Up	14.52 m
Operating Width	3.11 m
Height - Canopy	4.05 m
Maximum Truck Clearance	4.86 m
Minimum Right Cutting Radius	1.8 m
Minimum Left Cutting Radius	2 m
Conveyor Swing	60 degrees from center
Transport Length	12.43 m
Transport Width	2.74 m
Transport Height	3 m
