| Specification | Performance | ||
| bucket | backhoe | Rotational speed (rpm) | 9.1 |
| Working weight of the machine (kg) | 42100 | Walking speed (km/h) | 5.5/3.0/4.0 |
| Bucket capacity (m³) | 1.9 | Climbing ability (%) | 70/35 ° |
| Boom length (mm) | 7060 | Ground specific pressure (Kpa) | 78.2 |
| Bucket rod length (mm) | 3380 | Bucket digging force (kN) | 278 |
| Tonnage (ton) | 40 | Bucket rod digging force (kN) | 233 |
| Dynamic system | Hydraulic system | ||
| Rated power (kw/rpm) | 257/1900 | ||
| Displacement (L) | 11.04 | Maximum flow rate of main pump (l/min) | 690 |
| Number of cylinders (PCS) | 6 | Walking hydraulic circuit (Mpa) | 37.3 |
| Cylinder diameter × stroke (mm) | 125 x 150 | Rotary hydraulic circuit (Mpa) | 27.9 |
| Body size | Oil capacity | ||
| Total transport height (mm) | 3660 | Fuel tank (L) | 650 |
| Full cab height (mm) | 3285 | Hydraulic tank (L) | 248 |
| Track grounding length (mm) | 4020 | Engine oil replacement (L) | 37 |
| Total track length (mm) | 5055 | Coolant (L) | 36 |
| Track plate width (mm) | 600 | Scope of operation | |
| Total track width (mm) | 3340 | Maximum excavation radius (mm) | 12005 |
| Track gauge (mm) | 2740 | Maximum digging depth (mm) | 7790 |
| Minimum ground clearance (mm) | 567 | Maximum excavation height (mm) | 10925 |
| Total length of transport (mm) | 11940 | Maximum unloading height (mm) | 7625 |
| Total transport width (mm) | 3340 | Maximum vertical digging depth (mm) | 6600 |
