This Cat 390 excavator is a representative of super performance, with an operating weight of up to 80 tons, ensuring excellent performance in the most demanding environments.
Share :
Description
This Cat 390 excavator is a representative of super performance, with an operating weight of up to 80 tons, ensuring excellent performance in the most demanding environments. The powerful digging depth and powerful loading capacity deep into the ground help you handle ultra-large-scale projects. The perfect fusion of advanced technology and rugged design ensures reliable long-term operation. In addition, we can also provide a variety of accessories and configuration options for this Cat 390 excavator, such as hydraulic hammer, breaking bucket, rail device, etc., to meet different work needs.
Parameter
Specifications
Operating Weight 190016 lb
Swing Speed 6.2 r/min
Maximum Travel Speed 2.8 mile/h
Fuel Tank Capacity 327.57 gal (US)
Cooling System 26.68 gal (US)
Engine Oil 17.17 gal (US)
Bore 5.71 in
Stroke 7.2 in
Displacement 1104.5 in³
Main System - Maximum Flow - Total 258.89 gal/min
Swing System - Maximum Flow 121.52 gal/min
Maximum Pressure - Equipment - Normal 5076.3 psi
Maximum Pressure - Swing 3770.9 psi
Pilot System - Maximum Flow 23.78 gal/min
Pilot System - Maximum Pressure 597.56 psi
Boom Cylinder - Bore 8.27 in
Boom Cylinder - Stroke 77.44 in
Color YELLOW
Maximum Digging Depth: 9920mm
Maximum Digging Height: 11870mm
Max Digging Radius 7915mm
Condition Used
