Rotary Rig 20-65M New&Used | Machinery Global Supplier

Description

Designed for challenging terrain, this rugged rotary rig offers unrivaled drilling capabilities. With a drilling depth of 25m, it can easily, efficiently and accurately deal with deep drilling projects. Its advanced swivel system ensures seamless operation, while its solid construction ensures durability. Whether for foundation work, geotechnical exploration or mineral extraction, our rotary rigs are your ultimate partner for success. Elevate your drilling with this powerful and innovative powerhouse.

Parameter

Specifications

Model	KG410	KG410H
Weight	4500kg	4700kg
Dimension	615023502700mm	615023502700mm
Drilling hardness	f=6-20
Drilling diameter	Φ90-115mm
Economic drilling depth	25m
Rotation speed	120r/min
Rotary torque	2000N·m
Lifting force	40KN
Propulsion mode	Hydraulic Cylinders - Chain
Feed length	3980mm
Travel speed	0-2.5Km/h
Climbing capacity	≤30°
Ground clearance	280mm
Feed pitch angle	down 135° up50°
Feed swing angle	left 100° right45°
boom pitch angle	down 50° up25°
boom swing angle	left 44° right45°
Feed extension	900mm
Diesel engine	Yuchai YCD4R23T8-80(59KW/2400r/min)
Drill rod	64*3m
Toe-hole drilling	Min.350mm,Max.2840mm
