| Item | Unit | Value | Remarks | |
Working performance |
Max. rated lifting capacity | kg | 30000 | |
| Max. load moment of basic boom | kN.m | 990 | ||
| Max. load moment of main boom(fully extended) | kN.m | 624 | ||
| Max. lifting height of main boom | m | 42.1 | The parameters do not include deflection of main boom and jib | |
| Max. lifting height of jib | m | 50 | ||
Working speeds |
Max. hoist rope speed(Main winch) | m/min | 120 | At the 4th layer |
| Max. hoist rope speed(Auxiliary winch) | m/min | 120 | At the 4th layer | |
| Boom d-e-r-r-i-c-k-i-n-g up time | s | 25 | ||
| Boom telescoping out time | s | 84 | ||
| Slewing speed | r/min | 0 – 2.7 | 0 – 2.7 | |
Driving parameters |
Max. driving speed | km/h | 90 | |
| Max. gradeability | % | 42 | ||
| Min turning diameter | m | ≤20 | ||
| Min. ground clearance | mm | 260 | ||
| Oil consumption per hundred kilometers | L | 28 | ||
Mass |
Deadweight in driving condition | kg | 32510 | |
| Complete vehicle kerb mass | kg | 32389 | ||
| Front axle load | kg | 6610 | ||
| Rear axle load | kg | 25900 | 25900 | |
Dimensions |
Overall dimensions(L×W×H) | mm | 13150×2500×3450
