This 70t crane has a 5-section U-shaped main boom, a full arm length of 50 meters, a single-plate boom head and a compact boom tail, and leads the industry in high-frequency working conditions.
Share :
Description
This 70t crane has a 5-section U-shaped main boom, a full arm length of 50 meters, a single-plate boom head and a compact boom tail, and leads the industry in high-frequency working conditions. The 70-ton ultra-long main boom has a 15% advantage in lifting performance. In addition, this 70t crane uses an aluminum alloy air reservoir, which has good appearance quality and is corrosion-resistant.
Parameter
Specifications
item value
Parameter item QY70K5D-1
Size parameters 14985*2800*3830
Wheelbase 1470+4500+1350 mm
Axle load One axis 10,000 kg/two axes 10,000kg/three axes 13,000kg/four axes 13,000kg
engine model WP9H350E62
Engine rated power 276/1900(279/1900) kw/(r/min
Maximum driving speed 90km/h
Minimum stable driving speed 1.7~3km/h
Fuel consumption per 100 kilometers 43 L
Maximum rated total lifting capacity 70T
Minimum rated amplitude 3M
Maximum lifting moment of basic arm 2764 kN·m
Turntable tail turning radius 4400 mm
Longest main arm 50 m
The longest main arm + auxiliary arm 67
