32M Concrete Pump Truck Cost | Machinery Supplier & Exporter

Description

This concrete pump truck cost $87,500~$94,500. It has powerful pumping capacity and flexibility, and can easily handle the concrete delivery tasks of high-rise buildings and large-scale projects. Equipped with advanced hydraulic system and precise control system. This pump truck is stable and reliable, with excellent performance to ensure long-term operation. Whether it is a small construction project or construction in a narrow space, this 32m concrete pump truck can quickly help you complete the construction task.

Parameter

Specifications

Vehicle Dimension	Length	10350mm
	Width	2500mm
	Height	3610mm
	Total weight	20600kg
Boom & outrigger	No. of section	5
	Vertical reach	32m
	Horizontal reach	29m
	Reach depth	15.5m
1st section	length	7225mm
1st section	Articulation	0-90°
2nd section	length	5570mm
2nd section	Articulation	0-180°
3rd section	length	5260mm
3rd section	Articulation	0-245°
4th section	length	5205mm
4th section	Articulation	0-230°
5th section	length	5050mm
5th section	Articulation	±360°
Rotation		±360°
Distrance of front outriggers out		5584 mm
Distrance of rear outriggers out		6818mm
Pumping system	Theoretically output	93 m3/h
	Max. Strokes per minutes	32 times/min
	Delivery cylinder diameter	200mm
	Stroke length	1600mm
	Hydraulic system	Open loop
	Hydraulic system oil pressure	32Mpa
	Outlet pressure	7.9Mpa
	Oil tank capacity	500L
	Water tank capacity	550L
	Pipe line size	125mm
	End hose length	3m
	End horse diameter	125mm
Chassis	Chassis model	SINOTRUK,DFM
	Engine power	MAN 206KW
	Emission standard	National IV
	Displacement	6.87L
	Max. speed	80km/h
	Ground clearance	260
	Wheel base	5000mm

FAQ

If you have any other questions, please feel free to ask

Setting trade services and global marketing in one, and strive to be China's first-class international export group.

Tel : 0086-0371-63688886

How long will I receive the truck after payment? And what is your payment term?

Usually we accept T/T payment term for truck orders, but L/C payment is also acceptable under some special circumstances. About delivery time, normally it takes 30 days to produce your truck and deliver it to the port for loading after receiving your payment, but if you need it urgently, we can deliver it with the stored truck within one week.

Why is your price a little higher than other Chinese brand trucks?

Usually we accept T/T payment term for truck orders, but L/C payment is also acceptable under some special circumstances. About delivery time, normally it takes 30 days to produce your truck and deliver it to the port for loading after receiving your payment, but if you need it urgently, we can deliver it with the stored truck within one week.

What warranty do you provide for your Dongfeng truck?

Usually we accept T/T payment term for truck orders, but L/C payment is also acceptable under some special circumstances. About delivery time, normally it takes 30 days to produce your truck and deliver it to the port for loading after receiving your payment, but if you need it urgently, we can deliver it with the stored truck within one week.
