Equipment type | Unit | XAP123 | |
Complete machine | Theoretical rated productivity (5% water content) | t/h | 100-120 |
Temperature accuracy | ℃ | ±5 | |
Total installed power | kW | 337 | |
Length* width* height | m | 32*26.5*16.5 | |
Floor area | ㎡ | 848 | |
Cold hopper | Capacity | m³ | 4*9 |
Drying drum | Diameter | m | 1.8 |
Length | m | 7.7 | |
Fuel | Diesel, heavy oil/ natural gas | ||
Drying ability (5% water content) | t/h | 130 | |
Dust collector | Bag filter area | ㎡ | 480 |
Main mixing building | Screen layers | 4 | |
Screening area | ㎡ | 14.8 | |
Capacity of hot aggregate silo | m³ | 12.4 | |
Weighing capacity of aggregate | kg | 1500 | |
Weighing capacity of powder | kg | 300 | |
Weighing capacity of bitumen | kg | 130 | |
Mixing power | kW | 2*22 | |
Mixer capacity | kg | 1750 |
